*Текущая стоимость 2 445,22 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
![]()
![1]()
![1]()
![1]()
![1]()
![335]()
Силы начальной ()
{
/------ Код инициализации --------------/
/--- ST7735S последовательности сброса --------/
Сброс =-1 шт.;
/
DelayX1ms(1);
/Задержка 1 мс
Сброс = 0;
/Потяните сброс pin low
DelayX1ms(20);
/Задержка 10 мс
Сброс =-1 шт.;
/Потяните штифт сброса
/Сброс ST7735S ST7735S/
DelayX1ms(150);
/Это время задержки необходимо
Write_command (0x11); /Sleep out
DelayX1ms(120); /задержка 120ms
/ST7735S частота кадров ST7735S/
Write_command (0xB1);
Write_parameter (0x05);
Write_parameter (0x3C);
Write_parameter (0x3C);
Write_command (0xB2);
Write_parameter (0x05);
Write_parameter (0x3C);
Write_parameter (0x3C);
Write_command (0xB3);
Write_parameter (0x05);
Write_parameter (0x3C);
Write_parameter (0x3C);
Write_parameter (0x05);
Write_parameter (0x3C);
Write_parameter (0x3C);
/Sgs End ST7735S частота кадров ST7735S/
Write_command (0xB4); /Dot inversion
Write_parameter (0x03);
/ST7735S ST7735S последовательная индикация/
Write_command (0xC0);
Write_parameter (0x28);
Write_parameter (0x08);
Write_parameter (0x04);
Write_command (0xC1);
Write_parameter (0XC0);
Write_command (0xC2);
Write_parameter (0x0D);
Write_parameter (0x00);
Write_command (0xC3);
Write_parameter (0x8D);
Write_parameter (0x2A);
Write_command (0xC4);
Write_parameter (0x8D);
Write_parameter (0xEE);
/ST7735S/ST7735S
Write_command (0xC5); /VCOM
Write_parameter (0x12);
/Write_command (0xC7); /VCOM
/Write_parameter (0x1f);
Write_command (0x36); /MX, MY, RGB mode
Write_parameter (0xC8);/00,08
/ST7735S гамма-серия ST7735S/
Write_command (0xE0);
Write_parameter (0x04);
Write_parameter (0x22);
Write_parameter (0x07);
Write_parameter (0x0A);
Write_parameter (0x2E);
Write_parameter (0x30);
Write_parameter (0x25);
Write_parameter (0x2A);
Write_parameter (0x28);
Write_parameter (0x26);
Write_parameter (0x2E);
Write_parameter (0x3A);
Write_parameter (0x00);
Write_parameter (0x01);
Write_parameter (0x03);
Write_parameter (0x13);
Write_command (0xE1);
Write_parameter (0x04);
Write_parameter (0x16);
Write_parameter (0x06);
Write_parameter (0x0D);
Write_parameter (0x2D);
Write_parameter (0x26);
Write_parameter (0x23);
Write_parameter (0x27);
Write_parameter (0x27);
Write_parameter (0x25);
Write_parameter (0x2D);
Write_parameter (0x3B);
Write_parameter (0x00);
Write_parameter (0x01);
Write_parameter (0x04);
Write_parameter (0x13);
/ST7735S гамма-серия ST7735S/
Write_command (0x3A); /режим 65k
Write_parameter (0x05);
Write_command (0x2A);
/Адрес настройки
Write_parameter (0x00);
Write_parameter (0x00);
Write_parameter (0x00);
Write_parameter (0x7f);
Write_command (0x2B);
/Y адрес настройки
Write_parameter (0x00);
Write_parameter (0x00);
Write_parameter (0x00);
Write_parameter (0x9f);
Write_command (0x29); /отображение
Write_command (0x2C);
} Долл. США
Силы sleep_in()
{
Write_command (0x10);
/Нормальный режим-> Режим сна в режиме
DelayX1ms(150);
} Долл. США
Силы sleep_out()
{
Write_command (0x11);
/Режим сна в режиме-> нормальный-режим
DelayX1ms(150);
} Долл. США
Void LCD_BlockWrite(kal_uint16 startx,kal_uint16 starty,kal_uint16 endx,kal_uint16 endy)
{
Write_command (0x2A);
/Адрес настройки
Write_parameter (0x00);
Write_parameter (startx);
Write_parameter (0x00);
Write_parameter (endx);
Write_command (0x2B);
/Y адрес настройки
Write_parameter (0x00);
Write_parameter (starty);
Write_parameter (0x00);
Write_parameter (endy);
Write_command (0x2C);
/Дисплей данных
} Долл. США
Void LCD_blockClear(kal_uint16 startx,kal_uint16 starty,kal_uint16 endx,kal_uint16 endy, kal_uint16 data)
{
Kal_uint16 LCD_x;
Kal_uint16 LCD_y;
Write_command (0x2A);
/Адрес настройки
Write_parameter (0x00);
Write_parameter (startx);
Write_parameter (0x00);
Write_parameter (endx);
Write_command (0x2B);
/Y адрес настройки
Write_parameter (0x00);
Write_parameter (starty);
Write_parameter (0x00);
Write_parameter (endy);
Write_command (0x2C);
/Дисплей данных
Для (LCD_y = y1; LCD_y<= y2; LCD_y + +)
{
Для (LCD_x = x1; LCD_x<= x2; LCD_x + +)
{
# Условной LCD_16BIT_MODE
LCD_DataWrite (данные);
# Else
* (Летучий kal_uint8 *)LCD_DATA_ADDR = (data & 0xFF00)> 8;
Delay_ms(1);
* (Летучий kal_uint8 *)LCD_DATA_ADDR = data & 0xFF;
# Endif
} Долл. США
} Долл. США
} Долл. США
