Dahua оригинальная IPC HDBW4431F AS 4 МП HD POE Встроенный микрофон слот для sd карты H.265 IP67 IK10 20M

Dahua оригинальная IPC HDBW4431F AS 4 МП HD POE Встроенный микрофон слот для sd карты H.265 IP67 IK10 20M

Important notice ：To avoid unnecessary troubles, the products and packages on the images we show are all have no logo, but the products are shipped with logo ,they are original and updateable, Please feel free to place your order ~!

Dahua Original IPC-HDBW4431F-AS 4MP HD POE Built in MiC SD Card Slot H.265 IP67 IK10 Starlight IVS Upgradeable Dome IP Camera

1. About camera :

This model is 100% original Dahua IP camera ,it support firmware updating !

2. About shipment :

If you can order ≥ 4pcs cameras , we will try to send items via fast shipping for free .
We will choose the best shipping method for your order according to our experience as different countries has different shipping rules . Besides , wish you kindly understand that we could not remove the shipping cost for you if your shipping cost is too high .

3. About service :

Please contact our customer service if any doubt , We can support Skype/WhatsApp/WeChat , please contact our customer service to get the ID because we can't leave any contact information here as the rule of aliexpress .

Model:  IPC-HDBW4431F-AS-S2

1.Camera:
Image Sensor:  1/3” 4Megapixel progressive scan CMOS
Effective Pixels:  2688(H)x1520(V)
RAM/ROM:  512MB/32MB
Scanning System:  Progressive
Electronic Shutter Speed:  Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination:  0.08Lux/F2.0( Color,1/3s,30IRE)/0.3Lux/2.0( Color,1/30s,30IRE)/0Lux/F2.0(IR on)
S/N Ratio:  More than 50dB
IR Distance:  Distance up to 20m (66ft)
IR On/Off Control:  Auto/ Manual
IR LEDs:  10

2.Lens:
Lens Type:  Fixed
Mount Type:  Board-in
Focal Length:  2.8mm (3.6mm, 6mm optional)
Max. Aperture:  F2.0 (F2.0, F2.0)
Angle of View:  H: 104° (87°, 55°), V: 57° (48°, 31°)
Optical Zoom:  N/A
Focus Control:  Fixed
Close Focus Distance:  N/A

3.Pan/Tilt/Rotation:
Pan/Tilt/Rotation Range:  Pan:0˚~60˚; Tilt:0˚~80˚; Rotation:0˚~360˚

4.Intelligence:
IVS:  Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions:  Face Detection

5.Video:
Compression:  H.265+/H.265/H.264+/H.264
Streaming Capability:  3 Streams
Resolution:  4M(2688×1520)/3M(2304×1296)/1080P(1920×1080)/1.3M(1280x960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)
Frame Rate:  Main Stream: 4M(1~25/30fps)/Sub Stream: D1(1~25/30fps)/Third Stream: 720P(1~25/30fps)
Bit Rate Control:  CBR/VBR
Bit Rate:  H.264: 24~10240Kbps
H.265: 14~9984Kbps
Day/Night:  Auto(ICR) / Color / B/W
BLC Mode:  BLC / HLC / WDR(120dB)
White Balance:  Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:  Auto/Manual
Noise Reduction:  3D DNR
Motion Detetion:  Off / On (4 Zone, Rectangle)
Region of Interest:  Off / On (4 Zone)
Electronic Image Stabilization (EIS):  N/A
Smart IR:  Support
Defog:  N/A
Digital Zoom:  16x
Flip:  0°/90°/180°/270°
Mirror:  Off / On
Privacy Masking:  Off / On (4 Area, Rectangle)

6.Audio:
Compression:  G.711a/ G.711Mu/ AAC/ G.726

7.Network:
Ethernet:  RJ-45 (10/100Base-T)
Protocol:  HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;IGMP; SNMP
Interoperability:  ONVIF, PSIA, CGI
Streaming Method:  Unicast / Multicast
Max. User Access:  10 Users /20 Users
Edge Storage:  NAS/Local PC for instant recording/Mirco SD card 128GB
Web Viewer:  IE, Chrome, Firefox, Safari
Management Software:  Smart PSS, DSS, Easy4ip
Smart Phone:  IOS, Android

8.Certifications:
Certifications:  CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B

9.Interface:
Video Interface:  N/A
Audio Interface:  Built-in Mic
RS485:  N/A
Alarm:  N/A

10.Electrical:
Power Supply:  DC12V, PoE (802.3af)(Class 0)
Power Consumption:  <4.5W

11.Environmental:
Operating Conditions:  -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions:  -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection:  IP67
Vandal Resistance:  IK10

12.Construction:
Casing:  Metal
Dimensions:  Φ106mm×50.3mm (4.17”×1.98”)
Net Weight:  0.4kg (0.88lb)
Gross Weight:  0.44kg (0.97lb)

1. Original 4MP IPC-HDBW4431F-AS Dome IP Camera*1

2. Original Accessories
