Portable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | Инструменты



Сохраните в закладки:

Цена:US $395.01RUB
*Стоимость могла изменится

Количество:


Новое поступление

Graigar Instruments Store

Graigar Instruments Store

Магазина Graigar Instruments Store работает с 15.06.2011. его рейтинг составлет 80 баллов из 100. В избранное добавили 473 покупателя. Средний рейтинг торваров продавца 4.3 в продаже представленно 1613 наименований товаров, успешно доставлено 601 заказов. 50 покупателей оставили отзывы о продавце.

Характеристики

Portable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | Инструменты

История изменения цены

*Текущая стоимость US $395.01 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"

Месяц Минимальная цена Макс. стоимость Цена
Feb-20-2026 502.43 руб. 512.60 руб. 507 руб.
Jan-20-2026 407.53 руб. 415.51 руб. 411 руб.
Dec-20-2025 494.90 руб. 504.6 руб. 499 руб.
Nov-20-2025 490.73 руб. 500.48 руб. 495 руб.
Oct-20-2025 391.78 руб. 399.13 руб. 395 руб.
Sep-20-2025 482.70 руб. 492.10 руб. 487 руб.
Aug-20-2025 478.38 руб. 488.16 руб. 483 руб.
Jul-20-2025 474.16 руб. 483.45 руб. 478.5 руб.

Описание товара

Portable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | ИнструментыPortable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | ИнструментыPortable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | ИнструментыPortable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | ИнструментыPortable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | ИнструментыPortable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1um | Инструменты


ALIBABA-INSTRUMENT-TOP

Portable Coating Thickness Gauge CM-1210-200N Measuring Range 0~2000um/0~80mil Resolution 0.1um/1umr



Specifications

Principle F Magnetic Induction & NF Type Eddy Current
Range 0~2000µm/0~80mil
Resolution 0.1µm/1µm
Accuracy ±1~3%n or ±2.5µm
Min.Radius Workpiece F Type:convex 1.5mm/concave 25mm
NF Type:convex 3mm/concave 50mm
Min.Measuring Area 6mm
Min.Sample Thickness 0.3mm
Metric/Imperial
Functions Battery Indicator & Automatic Power Off
Data Memory ---------
Operating Conditions Temperature:0~40ºC
Humidity:10~90%RH
Power Supply 4x1.5V AAA (UM-4)Battery
Dimensions 140x72x34mm
Weight 215g(Not Including Batteries)



The F probes measure the thickness of non-magnetic materials on magnetic materials. The N probes measure the thickness of non-conductive coatings on non-magnetic metals.



Features:

* Two measuring methods: magnetic induction (F) and eddy current (N)
* Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.)
* Metric/imperial system selectable.
* Manual or automatic shut down.
* Automatic memory of calibration value,and automatic recognize the substrate.
* Operation process have buzzing reminder,while no buzzing in continuous mode.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
* Separate Type can provide several type probe, measure can be more flexibility.



Principle

Principles Applications Examples
F Type
Magnetic Induction
(Iron Base)
Measure the thickness of non-magnetic materials on magnetic materials Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc
NF Type
Eddy Current
(Aluminium Base)
Measure the thickness of non-conductive coatings on non-magnetic metals Anodizing, varnish, paint, enamel, plastic coatings, powder, etc. Applied to aluminum, brass, non-magnetic stainless steel, etc

CM-1210-200N(13)CM-1210-200N(5)CM-1210-200N(7)CM-1210-200N(9)CM-1210-200N(11)CM-1210-200N(4)CM-1210-200N(14)CM-1210-200N(3)
