DC 12V 12-channal 12CH Radio Controller RF Wireless Remote Control Switch System Transmitter Receiver Garage door Remote Switch

Specification & Description

Receiver

Channel: 12 CH
Control Types: Toggle, Momentary, Latched
Decode: Learning code
Frequency:433MHz
Power Supply (Operating Voltage): DC12V
Relay: 10A/120VAC, 10A/277VDC

Transmitter

Channel: 12 CH
Distance: 100 meter(open/ideal) in theory, 10%-50% in reality(In open environment,receiver antenna outside the box)
Encode: Fixed code, Soldering
Size: 125mm x 49mm x 20mm
Power Supply: 1 x 23A-12V battery

The way of output

A. 1-12CH Momentary-----Press Transmitter Button "1"to learn

B. 1-12CH Latched----- Press Transmitter Button "2" to learn

C. 1-12CH Toggle-- -- Press Transmitter Button "3" to learn

D.1-6CH Momentary, 7-12CH Latched ------Press Transmitter Button "4" to learn

E.1-6CH Momentary, 7-12CH Toggle------ Press Transmitter Button "5" to learn

F.1-4CH Momentary, 5-12CH Latched------- Press Transmitter Button "6" to learn

G.1-4CH Momentary, 5-12CH Toggle-------- Press Transmitter Button "7" to learn

H.1-4CH Toggle, 5-12CH Latched----------- Press Transmitter Button "8" to learn

Momentary------------Press the Transmitter button 1, the receiver relay 1th is ON, release button 1; the receiver relay 1th is OFF, the same as 2/3/4/5/6/7/8/9/10/11/12. 12CH are independent.

Toggle---------------Press transmitter button 1 for 1 time, the receiver relay 1th is ON, press button 1 again, the receiver relay 1th is OFF, the same 2/3/4/5/6/7/8/9/10/11/12. 12CH are independent.

Latched------------------

Press transmitter button 1, the receiver relay 1th is ON, the relay 2/3/4/5/6/7/8/9/10/11/12 OFF.

Press transmitter button 2, the receiver relay 2th is ON, the relay 1/3/4/5/6/7/8/9/10/11/12 is OFF.

Press transmitter button 3, the receiver relay 3th is ON, the relay 1/2/4/5/6/7/8/9/10/11/12 is OFF

Press transmitter button 4, the receiver relay 4th is ON, the relay 1/2/3/5/6/7/8/9/10/11/12 is OFF.

It also mean .Latched only can keep 1CH ON .and it will often have 1CH is ON.

3. Learning way and steps

1. Press the learning Button of the receiver and buzzer keep tweeting, indicate enter into the status of learning

2. Press the Relative button of the transmitter to learn Relative output way, indicate learning success as the buzzer tweet "Be Be Be" 3 sounds ,and then you press the transmitter Button you can hear the relay act sound. The receiver automatically exits learning state if you do nothing in 32 seconds.

4. Delete memory message (Must clear the code before you learn different button )

Keep pressing the learning Button of the receiver, the buzzer buzzer tweet and "Be Be Be Be " (please do not wait for it Be for 6 sounds) then release the button , indicate success to delete the memory message.

How to program the remote

The programming will be sent together with the goods.

Package includes

1 x Remote Control Switch
1 x Transmitter
